| Range | 1 — 100 Pa·s |
|---|---|
| Units | P, Pa·s |
| Repeatability | 1% of Reading (S.D., 20~30°C, No condensation) |
| Accuracy | ±3% (1~1000mPa·s) |
| Method | Tuning Fork Vibration Method (Natural Frequency at 30Hz) |
| Minimum Sample Amount | 10ml |
| Product Weight | 0.8kg / 1.7 lbs 1.3kg / 2.8 lbs |
Flexible and Versitale
- Wide measurement range: 0.3 – 10,000mPa.s for SV-10, and 1,000 – 100,000mPa.s for SV-100
- Measurement of very low viscosities (down to 1/3 of water viscosity!)
- Small size sample: cups of 35ml, 13ml, 10ml, and even tubes of 2ml (with SV-1A)
- Possible continuous measurements in order to characterize changes of state
- More application possibilities due to measurements taken directly into your containers of choice: beakers, product packages
Fast, Simple, and Accurate
- Fast measurements: 1st result within 15 seconds, and refresh in real time
- Simple operation: no configuration – just push the start button
- Calibration (judgement and even adjustment) of viscosity possible by the user: 1 or 2 points
- Simplified and automated calibration (including adjustment) with pure water (SV-10)
- High precision with a repeatability of ±1% of displayed value
- WinCT-Viscosity software for data acquisition on PC, graphic display of curves, and data archiving
Attention to Variables
- Temperature measurement from 0 to 160° C
- Vibration method allows for negligible thermal impact
- Low mechanical impact therefore can preserve sample characteristics and its texture
- Temperature control of sample with water jacket option (AX-SV-37) or other methods
